MODEL - CE 300/450
AUTOMATIC SLITTING SAW SHARPENING MACHINE
CE-SSM Saw Sharpeners are used by Sawing Machine users and Professional Saw Sharpeners alike, with literally number of machines in use. They are acknowledged market leader in this sieze range and renowned for their simplicity of operation and outstanding reliability.
SPECIAL FEATURES
A fundamental and prove feature of the CE-SSM is that the Saw blade is fed on to the fringing wheel on the principal that, being lighter than the grinding head, it is more easily moved without loss of speed or regidity. Two tooth forms can be generated through a system of cams without assorting of form grinding wheel and the popular high and lower tooth form can be ground. The machine is having the arrangement for chamfering to teeth as required. The standard machine is ready to operate and situated for grinding all popular metal cutting tooth forms as per DIN-1840. SAW blade grinding machine with pawl indexing for precise grinding of : HSS Saw Blade / Friction Saw / Segmental Saw.Technical Specification
Important Advantages
Technical Specification
| # | Technical Specification | Data |
|---|---|---|
| DIA OF BLADE CAN BE SHARPENED | ||
| 1 | Maximum Dia | 450mm |
| 2 | Minimum Dia | 100mm |
| CUTTING WIDTH OF BLADE | ||
| 1 | Maximum Thickness | 08mm |
| 2 | Minimum Thickness | 01mm |
| 3 | Pitch of Teeth | 02-18mm |
| 4 | Depth of Teeth | 02-12mm |
| 5 | Rake Angle | 0-25 |
| ELECTRICAL | ||
| 1 | Grinding Wheel Motor | 0.18 K.W. |
| 2 | Feed Mechanism | 0.37 K.W. |
| 3 | Dust Collector (Optional) | 0.37 K.W. |
| 4 | Weight of M/C (Approx) | 200 Kgs. |
Important Advantages
The grinding head can be raise and lowered for chamfering the teeth as required. The precision blade holder ensures accurate concentricity and incorporate and adjustable friction clutch.
